Projects

Where we work

Four project types, one set of disciplines. The engineering is largely the same; the environment, the standards and the consequences of getting it wrong are not.

Some projects overview

Ten scopes, photographed as they were built.

Machined seating in an engine room with resilient mounts bolted down, studs and nuts set, and timber packing alongside 01 Mechanical installation and piping · Shipbuilding

Engine room piping and machinery installation

Machinery on resilient mounts, and the seawater, bilge and fuel lines that connect it. The mounts went down first; the piping followed, through a compartment that was already full. Read the job ↑ Cylindrical steel unit in a fabricated frame, suspended on chain hoists over its marked position on the deck of a vessel under construction 02 Steel fabrication and mechanical installation · Shipbuilding

Foundations, penetrations and equipment installation

The steel that has to be in place before the equipment. We made and set the seats and frames, cut the openings and welded in the bulkhead penetrations, and fitted the supports for the cable and pipe routes. Read the job ↑ New large-bore pipework and a fabricated bend installed among existing lines and ducts inside an industrial plant 03 Mechanical installation and welding · Industrial

Large-bore pipe replacement

Large-bore pipework replaced inside an existing plant. We prefabricated the spools, rigged them into position on chain hoists off the plant steel, and welded them in place. Read the job ↑ Worker in disposable coveralls and respirator cutting seized steel free with an oxy-fuel torch at the grate, with removed grate blocks in the foreground 04 Mechanical maintenance · Waste to energy

Grate bar replacement

Grate bars replaced inside the furnace of a waste-to-energy plant during the outage. The old bars came out one row at a time, cut free where they were seized, and the new ones went back set to the specified gap. Read the job ↑ New blue centrifugal fan installed on a steel base on an outdoor grating platform, its outlet connected through an expansion joint to the existing painted exhaust stack 05 Mechanical installation and welding · Industrial

Fan replacement and duct adaptation

An extraction fan replaced on a process platform. The ducting that was already there did not suit the new unit, so we cut it back, made the transition pieces to fit, and connected the fan on both sides. Read the job ↑ Rope access technician suspended in a harness on the outside of an offshore platform, with wind turbines on the horizon 06 Welding and rope access · Offshore

Offshore rope access welding

Welding on the outside of an offshore platform, carried out on rope access. There is no scaffold and no basket over the side, so the welder reaches the joint on ropes and works from the harness. Read the job ↑ Welder working under a tank shell held up and secured on timber packing, with bottom plates laid out on the shop floor 07 Shop fabrication and welding

Tank and vessel fabrication

We weld the nozzles into the courses before they go on the stack, weld out the seams under a crane, and cut and fit the bottoms on the shop floor. Read the job ↑ Valve station under temporary cover at the base of a storage tank 08 Mechanical installation and welding · tank farm

Valve station and tie-in piping

A new valve station at the base of a storage tank. We set and levelled the valves, fitted the spools, welded and bolted the joints, and tied the run into the existing pipe rack. Read the job ↑ External bracket welded to a pad plate on the tank shell, with the pad welded all round 09 Mechanical installation and welding

Tank internals, nozzles and attachments

Internal pipe off a shell nozzle, brackets on pad plates, roof rafters into the centre ring. Read the job ↑ Agitator shaft running the full height of a storage tank up to the roof, with the upper impeller near the top 10 Mechanical installation

Agitator replacement inside a storage tank

The shaft runs from the drive mounting on the roof down to a bearing at the floor, with two impellers on it. Read the job ↑

From site

Photographs from delivered and in-progress scopes.

TIG root pass on a prefabricated spool
Carbon steel lines being set out on a plant roof
Process lines run alongside insulated ductwork
Stainless pipework around a transformer package
Completed pipe runs at a substation
Pipe runs erected along a plant facade
Mechanical package installed beneath the bushings
Cooling and process lines at the transformer plant
Vessel and pipe run carried along the building line
Pipe rack running to storage tanks at a fuel terminal
Pump skids and valve stations, terminal loading area
Pipe rack and cable trays on the loading gantry
Valve manifolds over the bund
Completed tank farm pipe racks
